HUUM Thermal Plate for HIVE Flow LS (Tunnel) Wood Burning Sauna Heater
HUUM Thermal Plate for HIVE Flow LS (Tunnel) Wood Burning Sauna Heater
Couldn't load pickup availability
Description
Description
The HUUM thermal plate for the HIVE Flow LS (Tunnel) wood-burning sauna heaters is a protective bedding for saunas where the heater stands on a wooden floor. It is also recommended where there is underfloor heating, protecting both the floor and the pipework beneath, and it carries a maximum load of 300 kg on six adjustable feet. Two sizes are available: 550 × 680 mm for the HIVE Flow LS and 500 × 630 mm for the HIVE Flow Mini LS.
Features
Technical Specification
| All models | |
| Purpose | Protective bedding for wooden floors and underfloor heating |
| Maximum load-bearing capacity | 300 kg |
| Feet | 6 adjustable feet, 56–65 mm height |
| Flow LS | |
| Compatibility | HUUM HIVE Flow LS (Tunnel) |
| Dimensions | 550 × 680 mm |
| Part number | H3016011 |
| Flow Mini LS | |
| Compatibility | HUUM HIVE Flow Mini LS (Tunnel) |
| Dimensions | 500 × 630 mm |
| Part number | H3018011 |
Installation
Remove the protective film, fit the six feet with their nuts and set the bedding in place. The plate must be levelled so that every foot carries weight, and each nut must then be screwed up against the underside of the plate to give the full load capacity. The fitting guide is available in the Downloads tab.
Brand
HUUM is an Estonian sauna manufacturer known for minimalist design and smart heater technology; its DROP heater won the Red Dot Award for Product Design in 2015.
Ordering note
Check your heater model before ordering: the 550 × 680 mm plate is sized for the HIVE Flow LS and the 500 × 630 mm plate for the HIVE Flow Mini LS. The thermal plate for other HIVE heaters is listed separately.
